| Referencia | Potencia, HP | RPM | Carcasa | Diámetro eje | Protección | F.S. | Tensión (V) | Corriente AMP@220V |
| CD001361HSB | 1 | 3600 | Nema 56 | 5/8″ | ODP | 1.25 | 110/220 | 6.5 |
| CD001181HSB | 1 | 1800 | Nema 56 | 5/8″ | ODP | 1.15 | 110/220 | 6.7 |
| CD002361HSB | 2 | 3600 | Nema 56H | 5/8″ | ODP | 1.15 | 110/220 | 11.0 |
| CD002181HSB | 2 | 1800 | Nema 56H | 5/8″ | ODP | 1.15 | 110/220 | 10.9 |
| PG003361HSB | 3 | 3600 | Nema 56H | 5/8″ | ODP | 1.00 | 110/220 | 15.4 |
| CD003181HSB | 3 | 1800 | Nema 56H | 5/8″ | ODP | 1.00 | 110/220 | 14.9 |
| PG005361GSA | 5 | 3600 | IEC 112M | 28 mm | ODP | 1.25 | 220 | 22.0 |
| PG005181GSA | 5 | 1800 | IEC 112M | 28 mm | ODP | 1.25 | 220 | 25.6 |
| PG005361CSD | 5 | 3600 | IEC 112M | 28 mm | TEFC | 1.15 | 220 | 20.8 |
| PG005181CSD | 5 | 1800 | IEC 132S | 38 mm | TEFC | 1.15 | 220 | 23.2 |
